Timewave PK-232MBX - Appendix E - Specific Radio Connections

PK-232 MBX – OPERATING MANUAL SPECIFIC RADIO CONNECTIONS
96/1 E-2 218
SPECIFIC RADIO CONNECTIONS
ALINCO Figure Note
ALD-24T 1
ALR-22HT 1
ALR-22T 1
ALR-72T 1
DJ-100 45
DJ-120T 45
DJ-160T 5 2
DJ-162T 5 2
DJ-180T 5 2
DJ-200 45
DJ-500 45
DJ-560T 5 2
DJ-580T 5 2
DJ-F1T 5 2
DJ-G1T 5 2
DR-110T 1 1
DR-112T 1 1
DR-119T 2 1
DR-1200T 2 1
DR-130T 50 1
DR-430T 1 1
DR-510T 1 1
DR-570T 1 1
DR-590T 3 1
DR-592T 3 1
DR-599T 3 1
DR-600T 3 1
AZDEN Figure Note
All W/ 12-PIN CONN 46
All W/8-PIN AMP 4
PCS-2000 46
PCS-5000 4
PCS-6000 4
PCS-7000 4
COLLINS Figure Note
KWM-380 6
DRAKE Figure Note
T4X 8 8
T4XB 8 8
T4XC 8
TR-22 7
TR-3 8
TR-33 7
TR-4 8 8
TR-4C 8 8
TR-4CW 8
TR-6 8 8
TR-7 7
UV-3 7
ICOM Figure Note
IC-02 SERIES 5 2
IC-03 SERIES 5 2
IC-04 SERIES 5 2
IC-12 5 2
IC-120 12 3
IC-1201 12 3
IC-1271 SERIES 12 3
IC 1275 SERIES 12 3
IC-12G SERIES 5 2
IC-2 SERIES 5 2
IC-20 10
IC-202 11
IC-21 10
IC-211 15
IC-215 11
IC-22 10
IC-228 SERIES 12 3
IC-229 SERIES 49
IC-22A 10
IC-22S 11
IC-22U 12 3
IC-230 10
IC-2330 SERIES 49
IC-2400 12 3
IC-2410 SERIES 49
IC-245 11
IC-24AT 5 2
IC-25 SERIES 12 3
IC-2500 12 3
IC-251 15
IC-255 12 3
IC-255 14
IC-260 12 3
IC-260 14
IC-27 SERIES 12 3
IC-271 SERIES 12 3
IC-275 SERIES 12 3
IC-28 SERIES 12 3
IC-280 11
IC-281 51
IC-281 52 6
IC-290 SERIES 12 3
IC-2G SERIES 5 2
IC-2GX 5 2
IC-21 SERIES 5 2
IC-2S SERIES 5 2
IC-2SR SERIES 9
IC-3SERIES 5 2
IC-30 10
IC-3200 SERIES 12 3
IC-3210 SERIES 12 3
IC-3220 SERIES 12 3
