4 RX-80
Any static-electricity discharge from the spray gun is to be diverted to the
grounded high-pressure pump via the conductive high-pressure hose as
stipulated.
The maximum surface temperature corresponds to the permissible
material temperature. This and the permissible ambient temperature can
be found in the Technical Data.
To avoid the generation of machine sparks, prevent impact stresses and any
work on the unit with tools in the explosion-hazardous area.
RESIDUAL RISKS
Residual risks are risks, which cannot be excluded, even when equipment is
used for the intended purpose.
In such cases the applicable areas of the actual residual risks will be pointed out
using warning and/or prohibition signs.
Risk Source / Cause Impact Preventative
measures
Can occur
during:
Injection
injury
Atomized, high
pressure stream
of uid
Severe
injury or
amputation
NEVER aim the
gun at any part of
the body
Setup,
Operation
Explosion
or re
Static electricity
or sparks
Severe injury Use well
ventilated area
Ground the spray
gun
Operation
Hazardous
vapors
Hazardous vapors
from spray
material
Severe injury Use well
ventilated area
Use mask
Operation
TECHNICAL DATA
Max. operating pressure 25 MPa (3600 PSI)
Material inlet thread size NPSM 1/4” (M16 x 1.5)
Diuser thread size 7/8 - 14 UN-2A
Wetted parts material High-grade steel, aluminum, PTFE, hard metal
Operating temperature range 40ºF to 104ºF (5ºC to 40ºC)
Maximum material temperature 109ºF (43ºC)
Maximum sound output 81 dB(A)*
Weight 599 g (1.3 lb.)
* Measurement location: 0.5 m away from the coating surface, 0.5 m behind
the spray gun, spray pressure 12 MPa, tip size 0.021
