Connections and buttons
This section provides illustrations of the following:
 Front panel buttons/connections on page 11
 Back panel buttons/connections on page 12
 Bottom buttons/connections on page 13
Front panel buttons/connections
Figure 2–1: TiVo Mini Front Panel
Single Bicolor LED
White: Powered on.
Amber: IR activity or
button presses.
MSO
Branding
Product
Branding
