6 Orion
6.1 Applications
The Orion can be used for a range of applications. Extra features include:
• End-to-End security (RS485 card reader)
• RS485 communication bus (kpBus)
• Replacement of existing Orbit reader
• Additional functionality
6.2 Required software versions
In order to guarantee optimum performance, the following software versions are required:
Version
Supported
iProtect
version
Orion
firmware
Applicatie: 1.1.26
Bootloader 2.0.1
Functional replacement for Orbit reader;
kpBus communication
≥ 8.03
Applicatie: ≥ 1.4.37
Bootloader ≥ 2.3.0.14
Functional replacement for Orbit reader;
kpBus communication; calamity card (SD-
card); Sirius Pincode based on Clock- data/
Wiegand protocol; NO/NC-output behavior;
provisioning; connection to Pluto
≥ 8.04
6.3 Functions and support
Depending on the desired application of the Orion, a range of functions are available. Below is a
list of functions.
6.3.1 Orion – connected to the Pluto
Type of controller
connected:
Pluto
Number
Connection
Digital input
2
T1, T2
Digital output
8
O1, O2, O3, O4, O5, O6, H1 and H2
Monitored inputs (ADC)
6
A1, A2, A3, A4, A5, A6
Orion override input
1
T
Wiegand/ABA card reader
2*
LD, D0, D1, C and V+
kpSensor
2**
C, S
Location buzzer
Yes
Status LED
Yes
MicroSD card
-
RJ45 – PRT1
RS485 card reader or Orbit
RJ45 – PRT2
kpBus communication or RS485 card reader or Orbit
Indoor temperature sensor
Yes
Power supply measurement
Yes
