TKH KEYPROCESSOR Pluto User Manual

46
11 How to
11.1 Installation Pluto
Configuring the Pluto:
1. Make sure all connections are in accordance with the technical drawing and connect the Pluto
to the network. See chapter 14.
2. Open the Explorer and browse to the following address: https://192.168.1.195. The login
screen appears.
3. Enter “controller” as username. The default password is “Pluto”.
4. On the maintenance page select “Network settings” and enter the desired information like IP
address and IP address gateway.
5. Select “Hardware” and activate “Diagnostics”. Diagnostics enables automatic detection of
devices connected to the Pluto and testing of it. Deactivate diagnostics after successful test.
6. Select “Tools” and verify the connection with iProtect™ by entering the IP address of the
iProtect™ server together with port number 20100 at Netcat and press the “Test” button.
Configuration in iProtect™:
1. Open menu “Installation” > “Hardware” > “Line”
2. Click on the “Search” button.
3. Make a right mouse click in the tree view (left side). “Add line” appears and click on this pop-
up. The line dialog will be opened.
4. Enter a logical description of the line in the field “Name”.
5. Enter the correct IP address in the field “IP address”.
6. Under communication select “Active” and “Active (with nodes)”.
7. Click on the “Save” button.
8. Press the button “Send new Keystore”.
When having the connection between iProtect™ and the Pluto in place, automatically the latest
software update will be installed on the Pluto. This may take a few minutes. When finished, the
“Current status” will be “Idle”.
NOTE
After the Pluto has communicated with iProtect™, the standard password will be
changed. The new password will be displayed in the “Line details” screen.
9. The nodes and readers connected to the Pluto can be automatically detected and configured
in iProtect™ by clicking on the “Read in” button at the “Line details” screen.
10. To activate the readers, an access card needs to be presented twice at each reader. As soon
as the LED of the reader is blinking when the card is presented, the correct card data will be
stored in iProtect™.
11. Assign a reader group, e.g. All card readers to the new card reader.
12. Finally assign a card, having the correct access profile to a person and verify if access in
granted. In case of access, the LED on the reader turns green for a period of 5 seconds.
