--- Orion test >> snr: 140025, V1.0.20 ---
Reader & IO-1
---------------------------- ---------------------
Input A1: off 128 (15939ohm) 1) Output O1: On/Off
Input A2: off 128 (15939ohm) 2) Output 02: On/Off
Input A3: off 128 (15939ohm) 3) Output O3: On/Off ----- general ----
Input T1: Off 128 4) Output H1: On/Off B)Buzzer : Off
Input D0: off 128 5) RdrLED R1 toggle
Input D1: Off 128 Input T :off 128
Input(v) :26.58V
Reader & IO-2 Reader(v):12.00V
--------------------------- ---------------------- Reader(a): 0.05A
Input A4: off 128 (15939ohm) 6) Output O4: On/Off Temp(K) : 240.0K
Input A5: off 128 (15939ohm) 7) Output 05: On/Off
Input A6: off 128 (15939ohm) 8) Output O6: On/Off
Input T2: Off 128 9) Output H2: On/Off
Input D0: Off 128 A) RdrLED R2 toggle
Input D1: Off 128
Reader [1 or 2] (ABA) > 29748424
1-B).. : toggle output state F) change format S) : stop
Screen 3: Device functionality test, options and mode of an Orion
On the above screen, the inputs and outputs can be tested. Using keys 1 to 9 or A and B, the
outputs can be activated or deactivated. Keys 5 or a can be used to test the card reader LEDs
(rapidly press 5 times to turn on or off).
When a card is presented to one of the card readers, the relevant card information will be
displayed after the Reader field.
Option âFâ changes the way in which analogue input information is displayed (Ohms or raw
data).
To Next Page
