TKH KEYPROCESSOR Pluto User Manual

28
7.3.1.1 Connection of kpBus
NOTE If the kpBus begins with an Orion, the start and the end of the kpBus must have
an EOL jumper, see Figure 18: Pluto/Orion - kpBus.
Orion (I)
A B C S
TIA/EIA-568-B
Colour of the cable
Orion (I)
A B C S
B
White/orange
B
A
Orange
A
B
White/green
B
-
Blue
-
-
White/blue
-
A
Green
A
C
White/brown
C
C
Brown
C
Illustration of
kpBus
connection
PRT2
A B C S
I
Orion Pluto
PRT2
PRT2
PRT2
N
PRT2
kpBus
Max. 8
1 2 3
A B C
A B C
A B C
A B C
I
I
I
I
Max. 32x Orions
Max. 32x card readers
Figure 19: Pluto/Orion - kpBus with Clock- data / Wiegand and RS485 reader
PRT1
X
X X X
X
