TKH KEYPROCESSOR Pluto User Manual

22
Events
Nr.
Description
1
Push button access
2
Push button no access
3
Card access
4
Card no access
5
Card no calamity card
6
Emergency door release activated
7
Emergency door release deactivated
The following table shows all the inputs:
Inputs
Nr.
Connection:
Description:
Reader nr.
Invert (NO/NC)
1
A1
Loop (enable)
Reader 1
Yes
2
A2
Push button
3
T1
Emegency door release
4
A4
Loop (enable)
Reader 2
5
A5
Push button
6
T2
Emegency door release
The following table shows all the outputs:
Outputs
Nr.
Connection:
Description:
Reader nr.
Invert (NO/NC)
1
H1
Door lock
Reader 1
Yes
2
O1
Output
3
O2
Alarm
4
O3
Output
5
H2
Door lock
Reader 2
6
O4
Output
7
O5
Alarm
8
O6
Output
The following table shows the reader:
Reader
Nr.
Description:
Protocol:
Kaartdata
interpretation:
Pincode
function offline
1
Reader 1
Clock – data/ Wiegand
Max. 1
Pincode
switched off
2
Reader 2
Clock – data/ Wiegand
Max. 1
Note: It is possible to use combined input or output by a reader. Consider a door with a card
reader on both sides.
