HYDRAULIC CLUTCH LEVER
The Bembo clutch pump (1) is located on the left side of the handlebar.
The clutch lever (2) activates the detachment of the transmission from
the engine.
Fully pull the lever towards the grip to activate the clutch.
The position of the lever compared to the grip can vary depending on the
rider’s preference. See chapter 4.2 “Chassis Maintenance” (page 52).
MANUAL DECOMPRESSION LEVER (ALL 530F)
The manual decompression lever (1) is located on the left side of the
handlebar. It is used when, after a fall or overheating, the motor has
trouble hot starting. To ventilate the engine, pull the decompression lever
during start-up.
NISSIN PUMP FRONT BRAKE LEVER (EN/MX)
The Nissin front brake pump (1) is located on the right side of the handle-
bar. The front brake lever (2) activates the front wheel brake. The position
of the front lever compared to the grip can vary according to the rider’s
preference. See chapter 4.2 “Chassis Maintenance” (page 54).
BREMBO RADIAL PUMP FRONT BRAKE LEVER (SMR/SMM)
The Brembo front brake pump (1) is located on the right side of the
handlebar. The front brake lever (2) activates the front wheel brake. The
position of the front brake lever compared to the grip can vary according to
the rider’s preference. See chapter 4.2 “Chassis Maintenance” (page 55).
2
1
2.1 HANDLEBAR CONTROLS
2
1
2
1
1
