4 STROKES
KEY IGNITION SWITCH (SMR/SMM)
The SMR and SMM models are equipped with a cylinder (1) for the ignition
key on the left side of the dashboard.
To start the engine, insert the key and turn it clockwise. Use the starter
described on page 14.
To switch the engine off, use the kill switch described on page 14. Turn
the key anticlockwise and remove it from the cylinder.
START ENGINE BUTTON (MXE.S./SMXE.S.)
The start engine button (1) is located near the right grip on the handlebar.
Once the gear has been put in neutral, press this button to start the engine
and release it as soon as the engine is running.
Activate this control for a maximum of 8/10 seconds at a time and wait a
few seconds before trying again.
After 3/4 attempts, stop and try to identify whether there is a problem.
Never press this button when the engine is already running.
ENGINE STOP BUTTON (MX/SMX)
The engine stop button (1) is located near the left grip on the handlebar.
Press this button to switch the engine off and release it as soon as it is off.
MAP SELECTION SWITCH (ALL 250Fi - ALL 450Fi)
The map selection switch (1) is located on the left side of the handlebar.
This button (2) allows the rider to choose the injection mapping most
suitable to his/her preference and to the circuit conditions. Select Map
1 to activate a map that makes the engine response more aggressive.
Select Map 2 to activate a map that makes the engine response more
progressive.
2
1
2.1 HANDLEBAR CONTROLS
1
1
1
