4 STROKES
6.1 CHASSIS TECHNICAL DATA
CHASSIS TIGHTENING TORQUES
Front wheel pin flanged nut
Front brake calliper fix. screw (EN/MX)
Front brake calliper fix. screw (SMR/SMM/SMX)
Rear brake calliper fix. screw (SMM)
Front brake disc fix. screw
Rear brake disc fix. screw (EN/MX/SMR/SMX)
Rear brake disc fix. screw (SMM)
Upper fork head tightening screw
Lower fork head tightening screw
Marzocchi fork foot tightening screw
Kayaba fork foot tightening screw
Rear wheel pin flanged nut
Rear wheel nut (SMM)
Rear hub locking screws (SMM)
Swing arm pin flanged nut
Handlebar tightening cap screws
Handlebar elastic support nut
Upper shock absorber nut
Lower shock absorber screw
Sprocket nuts
Rear brake pedal adjusting nut
Engine fixing screw
Generic frame screws
Generic frame nuts
M20x1.5
M8
M10
M8
M6 cl. 10.9
M6 cl. 10.9
M8
M8
M8
M6
M8
M22x1.5
M50x1.5
M10
M16x1.5
M8
M10
M10x1.25
M10x1.25
M8
M6
M10
M6
M8
M10
M6
M8
M10
40 Nm
25 Nm
40 Nm
25 Nm
15 Nm
15 Nm
25 Nm
20 Nm
15 Nm
15 Nm
20 Nm
80 Nm
180 Nm
35 Nm
40 Nm
15 Nm
45 Nm
40 Nm
35 Nm
35 Nm
15 Nm
45 Nm
10 Nm
25 Nm
45 Nm
15 Nm
30 Nm
50 Nm
