TMT Automation CB236 - Page 11

11
Parameters Function Gate status Reaction
FB-0
PH1 Function off No function No function (Default setting)
FB-1
Photocell -Close
Gate fully close Not allow to open
Gate fully open Not allow to close
Stop during cycle Not allow to open/close
Closing phase Open
Opening phase No effect
FB-2
Photocell -Open
Gate fully close Not allow to open
Gate fully open Not allow to close
Stop during cycle Not allow to open/close
Closing phase No effect
Opening phase Close
FB-3
Safefty edge
Gate fully close Not allow to open
Gate fully open Not allow to close
Stop during cycle Not allow to open/close
Closing phase Open for 2 seconds
Opening phase Close for 2 seconds
FB-4
Fast close
Gate fully close Not allow to open
Gate fully open Auto close after 2 second
Stop during cycle Not allow to open/close
Closing phase Open
Opening phase No effect
Parameters Function Gate status Reaction
FC-0
PH2 Function off No function No function (Default setting)
FC-1
Photocell -Close
Gate fully close Not allow to open
Gate fully open Not allow to close
Stop during cycle Not allow to open/close
Closing phase Open
Opening phase No effect
FC-2
Photocell -Open
Gate fully close Not allow to open
Gate fully open Not allow to close
Stop during cycle Not allow to open/close
Closing phase No effect
Opening phase Close
FC-3
Safefty edge
Gate fully close Not allow to open
Gate fully open Not allow to close
Stop during cycle Not allow to open/close
Closing phase Open for 2 seconds
Opening phase Close for 2 seconds
FC-4
Fast close
Gate fully close Not allow to open
Gate fully open Auto close after 2 second
Stop during cycle Not allow to open/close
Closing phase Open
Opening phase No effect
Safety Device Logic
• FB PH1 Functions
• FC PH2 Functions
