5.4. Limiting The Number of Simultaneously Usable Delegate Units (TS-702)
Using the center amplifier's speaker restriction switch (MIC LIMITER), the number of simultaneously-usable
delegate units (TS-702) can be limited. Set the switch to 1, 2, 4 or 6 depending on the conference scale.
Sets the number of delegate units that
can be used simultaneously.
Center amplifier (TS-700) front panel
MIC LIMITER
1
2
4
6
The MIC LIMITER
switch is set to "2".
Delegate unit Delegate unit Delegate unit
Other delegate units cannot be used
even if the TALK button is pressed.
Two delegate units are in use.
Not usable
Center amplifier
(TS-700) front panel
1
2
4
6
Delegate unit Delegate unit Delegate unit
One more delegate unit can be used.
One delegate unit is in use.
Usable
The MIC LIMITER
switch is set to "2".
Center amplifier
(TS-700) front panel
1
2
4
6
Example: The speaker restriction switch is set to the "2" position.
Two delegate units can be used simultaneously. Other delegate units cannot be used even if the TALK button
is pressed.
If only one delegate unit is in use, up to one more delegate unit can be used.
The chairman unit can be used at any time regardless of the limitation of the number of usable
delegate units.
