TomTom RIDER 2nd Edition User Manual

12
•
•
•
•
•
•
2. Wrap the piece of rubber provided around the handlebars to make the
handlebars thick enough for the Handlebar Mount. Cut the piece of rubber
to adjust the thickness.
3. Place the Handlebar Mount around the handlebars and over the piece of
rubber.
4. Screw the Handlebar mount together tightly using the Allen key provided.
5. Screw the Holder to the Handlebar Mount using four of the small screws
included with the mounting kit.
If your TomTom RIDER is not in a comfortable position, unscrew the
Handlebar Mount slightly and adjust the angle of the mount and the holder.
Then screw the Handlebar Mount together tightly again.
You can now place your TomTom RIDER in the Holder. See this section:
Placing your TomTom RIDER in the Holder on page 15.
Handlebar adaptor
The Handlebar Adaptor is secured by bolts next to the grip, as shown.
Note: The piece of rubber helps prevent vibration and stops the Handlebar
Mount from slipping while you are driving.

TomTom RIDER 2nd Edition Specifications

General

Marine (chartplotters, sounders)	No
Map view options	2D/3D
Form factor	Fixed
Channels quantity	20 channels
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
Internal memory	32 MB
Power requirements	12V
Processor frequency	380 MHz
USB 2.0 ports quantity	1
Battery life (max)	5 h
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Depth	96.2 mm
Width	113.2 mm
Height	52.9 mm
Weight	310 g
