ToolKitRC M7AC - Specifications; Specifications overview

@ToolkiRC 2022
46
Specifications
Charge
Input
AC 100-240V@MAX 100W
DC 7-35V@MAX20A
Battery type
LiPo LiHV LiFe Lion LTO@1-6S
NiMh @1-16S PB @1-10S
Balance
800mA @4.2V
Accuracy
<0.005V
Power
0.1-15A@300W
Discharge
power
0.1-15A@300W Rec/Ext Mode
0.1-3A@15W Internal Mode
USB A
5.0V@10W or
upgrade
Voltage
1.0V-5.0V @1-6S
Internal
resistance
0.1mΩ-99mΩ @1-6S
Measure
PWM
880us-2200us@20-400hz
PPM
880us-2200us*8 CH@20-50hz
SBUS
880us-2200us*16 CH@20-100hz
Output
PWM
500us-2500us@20-1000hz
PPM
880us-2200us*8 CH@50hz
SBUS
880us-2200us*16 CH@74hz
Power
0.5-15A@1-28V Mode: CC+CV
Display
LCD
IPS 2.4 inch 320*240 resolution
Accessor
TF Card
Support 128MB-16GB
Product
Size
112mm*73mm*38mm
Weight
245g
Individual
packing
Size
144mm*125mm*43mm
Weight
380g
