Programming
1. Introduction
1.1 Program Name
The name of a Program in USB or in system has to be P+ number,
Like P1, P123, P1234
1.2 Code Explanation
Same Code might means differently in different place.
Code
Number Range
Meaning
N
0~9999
Sub program name
N
0~99999
Program Name
G
0~99
G code
X
+0.001~
+99999.999
(mm)
X axis
Y
Y axis
Z
Z axis
C
C axis
R
+0.001~
+99999.999mm
Radius
K
0.001~99999.999s
Delay Time
F
0~99999
Feeding speed
S
0~99999r/min
Spindle speed
M
00~99
M code
2.G Code
Non Modal G code：Valid only in this Program line
Modal G code: Valid until another G code of the same Group is used.
G Code
Modal
Format
Function
G00
Modal
G00 X_ Y_ Z_ C_
Fast Positioning
G01
G00 X_ Y_ Z_ C_ F_
Linear Interpolation
G02
G02/G03 X_ Y_ R_ F_
Clock wise Interpolation
G03
Counter Clockwise Interpolation
G04
G04 Kxxxxx.xxx
Delay Time: s
G20
G20 Nxxxx.xxx
Numbers after N ： subprogram name and
repeat times
Subprogram Call
G22
G22 Nxxxx
Numbers after N
：
subprogram name
Subprogram Start
