Topcnc TC55H User Manual

jiafengqi.xtf@hotmail.com
2
1. Product Introduction
TC55H is an upgrading version of TC55. It can control 4 feeding axis, 1 analog spindle. It is equipped with 16
input port and 8 output port, supporting importing files from USB stick.
2. Technical Specifications
Minimum data unit 0.001 mm
Maximum data size ± 99999.999mm
Maximum Speed: 9000mm/min (pulse is 0.001mm)
Maximum pulse output frequency 150KHz
Axis 1-4 (X,Y, Z,C)
X,Y,Z,C axis can conduct linear interpolation, X,Y can do circular interpolation.
Electric Gear: numerator :1-99999 denominator: 1-99999
USB: Importing program and boot picture
Isolated I/O port
Maximum Program Line: 5000
Maximum Program: 100
RAM: 128M
External Manual Operation: motor clockwise and counter clockwise spinning, start, pause, alert and stop
G code and M code
One panel MPG
3.5 inch color LCD, pixel 320*240
Analog Spindle Output: 1 0-10v analog spindle
Definition of external Switch
