Four Reference
How to use TC55H correctly?
1. Wiring according to instruction
2. After booting, press and find the button for code and log in.
3. Press PAR, then choose Output; Set M51, Output 1, Press Enter to turn the output port On; Set M52,
Output 1, maintain Off; Set M53, Output 2, Press Enter to turn On; Set M54, Output 2, stay Off; Press
ESC, then Enter to save.
4. Press PROG, then New, type in a name, then press ENTER, and then you can start to edit;
Program Line Explanation
N001 G90 Absolute Programming
N002 G00 X10 Y10 Fast Positioning
N003 G02 X30 Y20 R15 F800 Clockwise Interpolation
N004 M03 S500 Spindle Clockwise Spin
N005 M51 Output
N006 G04 K5 Delay
N007 M52 Output
N008 M04 S800 Spindle Counter Clockwise Spin
N009 M53 Output
N010 G04 K5 Delay
N011 M54 Output
N012 M05 Spindle Stop
N013 M02 End
5.Press Test, if there is no mistake, press Save, Then press Auto, and Start.
