8
● BMZ High: Go to machine zero at high speed.
● BMZ low: Go back to machine zero first at high speed, through zero switch and move back at low speed.
Finally slider will stop on the switch.
● BMZ Mode: two modes to go back to machine zero, trough switch or not. Through switch(0): slider will
stop on switch. Not trough switch(1): Slider will stop before the switch.
● S High Speed: The highest speed of spindle
4.3 Input
This function unable user to set various kind of switch easily. Define the I/O port according following form.
External Big switch is needed to finish external control. External switch is connected in the way of normal
open. Press R to change off into on, and S to choose N.O.(Normal Open). Then choose the IO Port number in
the blank.
Note: For safety consideration, limit and emergency stop input is usually set as N.C.(Normal Close).
Function
Explanation
Alert
Alert Input
Stop
Emergency Stop Input
Run
Outside(External) Run Switch Setting
Pause
Outside(External) Pause Switch Setting
Speed+
Feed rate increase Switch Setting
Speed-
Feed rate decrease Switch Setting
X Lim+
X axis Positive limit setting
X Lim-
X axis Negative limit setting
X 0
X axis zero switch setting
Man X+
X axis clockwise spinning outside manual switch
Man X-
X axis counter clockwise spinning outside manual switch
X Boot Zero
X axis go back to Machine zero after booting external manual switch
Y Lim+
Y axis Positive limit setting
Y Lim-
Y axis Negative limit setting
Y 0
Y axis zero switch setting
Man Y+
Y axis clockwise spinning outside manual switch
Man Y-
Y axis counter clockwise spinning outside manual switch
Y Boot Zero
Y axis go back to Machine zero after booting external manual switch
Z Lim+
Z axis Positive limit setting
