SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS AND PERFORMANCE
1) Only in CV-5000
2) The combination of the polarizing filter must be one of the following: 45°/135° and 135°/45° or 45°/135° and circular
polarizing filter.
* Specifications and appearance are subject to change without advance notice for the product
improvement.
DIMENSIONS AND WEIGHT
Main unit (Non-arm mounted type) Dimensions : 294 ~ 328mm (W) × 115mm (D) × 261mm (H)
Weight : 4kg
Main unit (Arm-mounted type) Dimensions : 294 ~ 328mm (W) × 115mm (D) × 324mm (H)
Weight : 4.6kg
PURPOSE OF USE
Used to measure the refractive power of eyes and perform the binocular function test.
OPERATION PRINCIPLE
On a disk built in the instrument, the lenses with a variety of refractive power are arranged. By
turning the disk, the lenses are changed to each other. There are two or more disks in the
instrument. So, measurement of different types can be carried out by selecting and combining
the disks.
ELECTRIC RATING
Power supply voltage : AC100-240V, 50-60Hz
Power supply input : 90VA
Spherical power
Measuring range +27.00 ~ -27.00D
Measuring step 0.25D/3.00D
Astigmatic power
Measuring range +8.00 ~ -8.00D
Measuring step 0.25D/1.00D
Cylinder axis
Measuring range 0 ~ 180°
Measuring step 1°/5°/15°
Prism
1)
Measuring range 0 ~ 20
Δ
(all direction)
Measuring step 0.1
Δ
/0.5
Δ
/1.0
Δ
Pupillary distance
adjustment range
Adjustment range 48 ~ 80mm
Adjustment step 0.5mm/1.0mm
Cross cylinder
Jackson Cross cylinder ±0.25D/±0.50D
Auto Cross cylinder
1)
±0.25D
Test lens (Aux lens)
Red-Green filter, Polarizing filter (45°/135°, Circular Polarizing Filter
1)
)
2)
, Prism
(6
Δ
/10
Δ
), Red Maddox (horizontal/vertical), Lens for retinoscopy (+1.5D/
+2.0D), Cross cylinder for measuring presbyopia (±0.50D), Occluding plate
(right/left), Pinhole, and Cross hairs glass (right/left).
Cornea alignment scale
(on optical axis)
12mm, 13.75mm, 16mm, 18mm, 20mm
Convergence
Near-point distance 40/67cm
(Minimum papillary distance at 40cm convergence : 53mm)
Forehead rest
adjustment range
15mm
Tightening torque
condition of knob
300Ncm
Essential performance
Lens changing function
