FOREWORD
Safety Standard for Laser Beam
(Only for GTS-230W series Plumb Laser Type)
GTS-230W series plumb laser type uses the visible laser beam. The GTS-230W series plumb laser
type are manufactured and sold in accordance with "Performance Standards for Light-Emitting
Products" (FDA/BRH 21 CFR 1040) or "Radiation Safety of Laser Products, Equipment Classification,
Requirements and User`s Guide" (IEC Publication 60825-1) provided on the safety standard for laser
beam.
As per the said standard, the GTS-230W series plumb laser type is classified as "Class 2 (II) Laser
Products".
In case of any failure, do not disassemble the instrument. Contact TOPCON or your TOPCON dealer.
Labels
Find the labels which describes the caution and safety about the laser beam as follows in GTS-230W
series.
We request you to replace it one anytime the caution labels are damaged or lost and paste a new one
at the same place. You can get the labels from Topcon or your dealer.
Symbol mark while the laser is emitting.
The following symbol mark will appear at the
right side of the second line.
AVOID EXPOSURE
LASER LIGHT IS EMITTED
FROM THIS APERTURE
CLASS 2 @ LASER PRODUCT
DO NOT STARE INTO BEAM
LASER RADIATION
Maximum output 1W @ Wave length 633nm
Beam aperture
Warning Label
Aperture Label
GTS-230W series
Laser Plummet type
Explanatory Label
Depending on the country where the instrument is sold, either of these labels may be
found on the GTS-230W series laser plummet type.
CLASS II LASER PRODUC
T
WAVE LENGTH 633nm
1mW MAXIMUM OUTPUT
LASER RADIATION-DO NOT
STARE INTO BEAM
CAUTION
TILT SENSOR:[XY-ON]
X:-0°00'25"
Y: 0°00'20"
X-ON XY-ON OFF L.PL
Symbol mark

Topcon GTS-235W Specifications

General

Brand	Topcon
Model	GTS-235W
Category	Measuring Instruments
Language	English
