38
* The beam can now be moved manually for precise alignment on the control point.
Refer to page 39 “Fine movement of the beam after completing alignment”.
Operating range error
The range of line control is ±5 degrees.
When the range has been exceeded, the red LEDs will flash alternately and the rotary
head will return to within 3 degrees of 0°.
Reset the instrument.
