TOPSHINE TRACKING TECHNOLOGY USER MANUAL OF MT100
- 29 -
3. Command List
Description Command Reply SMS
Configure authorized RFID tag
W<password>,060,num1
W<password>,160,num2
W<password>,260,num3
W<password>,360,num4
W<password>,460,num5
STUDY ID OK: 1:num1; 2:num2;
3:num3; 4:num4; 5:num5;
The next SMS: NOW ID………
Enable the RFID detection
W<password>,062,1
ENABLE OK !
Disable the RFID detection
W<password>,062,0
DISABLE OK !
Arm
<password>ARM
Vehicle is armed!
Disarm
<password>DSM
Enable function of cutting off
oil-way when illegally ignite
under ARM status
W<password>,061,1
Disable function of cutting off
oil-way when illegally ignite
under ARM status
W<password>,061,0
System default setting is disable
function of cutting off oil-way
when illegally ignite under ARM
status.
4. Functions
4.1 To ignite in armed status, it will check the RFID tag. If an authorized tag can be
detected, it will not alert. If an authorized tag can not be detected, it will send alert SMS
“Engine Is On!” to three authorized alert mobile phone numbers, and at the same time, the
Output 3 will control siren to sound, and call the three mobile phones at one minute interval,
and decide to cut off the oil/fuel supply according to its oil cut enable/disable status.
4.2 If vehicle door is opened in armed status, it will check the RFID tag. If an authorized
tag can be detected, it will not alert; if an authorized tag can not be detected, it will send alert
SMS “Door Is Open !” to three authorized alert mobile phone numbers, and the Output 3 will
control the siren to sound, and call the three mobile phone numbers at one minute interval.
4.3 If the vehicle is moved/towed in armed status, it will detect the RFID tag, if no
authorized tag be detected, it will send alert SMS ”Movement alarm!” to the 1
st
alert mobile
phone number.
4.4 In disarmed status, if no authorized RFID tag Is detected for successive 30 seconds,
then the system will automatically arm the vehicle, and it will call the 1
st
alert mobile phone
