TOPSHINE TRACKING TECHNOLOGY USER MANUAL OF MT100
- 7 -
5.2 Charging
Connect the device with external power like car battery, and turn on its power switch, then it
will do charging automatically
5.3 LED Indications
Push the power switch to turn on/off MT100
GPS LED (Red)
Flashing ( every 0.1 second) Initializing or back-up battery power is low
Flashing (0.1 second on and 2.9 seconds off)
MT01 has a GPS fix
Flashing (1 second on and 2 seconds off) MT01 has no GPS fix
GSM LED (Green)
Flashing ( every 0.1 second) Initializing
Flashing (0.1 second on and 2.9 seconds off)
MT01 is connected to the GSM network
Flashing (1 second on and 2 seconds off) MT01 is not connected to the GSM network
