TOPSHINE TRACKING TECHNOLOGY USER MANUAL OF MT100
- 5 -
3.2 Specifications
Items Specifications
Dimension 80*58*22mm
Weight 92g
Charging voltage +9V~+24V
SIM Card type 3V
Power consumption Active mode(peak)<1.0 A
Active mode(avg.)<300 Ma
Idle mode <50 mA
Operating temperature -20~+75 ℃
Humidity Up to 75% non-condensing
External SIM card Connected via SIM card connector
External Antenna Connected via 50 Ω coax connector
Button 1 SOS and 1 power on/off
Microphone Optional
Transmit power Class 4(2W) for E-GSM 900 and 850
Class 1(1W) for DCS 1800
Class 1(1W) for PCS 1900
Sensitivity -104dBm minimum for E-GSM 900 AND 850
-102dBm minimum for DCS 1800
-102dBm minimum for PCS 1900
GPS chip Latest GPS SIRF-Star Ⅲ chipset
GPRS Multi-slot Class 8(4Rx, 1Tx., 5slot Max.)
Support all 4 coding
schemes(CS-1,CS-2,CS-3 and CS-4)
Maximum download speed is 85.6kbps
Maximum upload speed is 21.4kbps
Speech Codec
Triple rate Codec
Half rate—ETS 06.20
Full rate—ETS 06.10
Enhance full rate—ETS 06.50/06.06/06.08
I/O 3 Output, 2 Input, 1 Analog input and 1 RS232
port
