18 Instructions for use T-1321 e
System Behaviour No. Cause Remedy/ Rectification
The door opens slowly. E32
E38
The safety facility in the opening di-
rection is permanently active
(> 1 minute) or defective.
Remove objects from within the
range of the sensor(s). Otherwise
have the system repaired by an
expert.
The door remains
open.
E33
E39
The safety facility in the closing di-
rection is permanently active
(> 1 minute) or defective.
Remove objects from within the
range of the sensor(s). Otherwise
have the system repaired by an
expert.
The door remains open. E41
E42
E43
Activator inside is active > 1 min.
Activator outside is active > 1 min.
Key switch is active > 1 min.
Get sensor adjusted by an expert.
Reset the key switch.
Door remains open. E46 Emergency opening monitoring
> 10 min. active
Have the system repaired by an
expert.
The door stands still. E51 Encoder defective. Have the system repaired by an
expert.
The door stands still. E53
E54
E55
E56
Anomaly in the travel distance.
Solid obstruction in the movement
area.
Remove firm obstacle in the trav-
elling range of the door.
Perform a software-reset.
Have the system repaired by an
expert.
The door stands still. E61
E62
E63
Power supply is overloaded or volt-
age too low.
Get the power supply and connec-
tions checked by an expert.
The door stands still. E64
E65
Drive/control system is overheated. Wait for the automatic reset after
the door/control system has
cooled.
Protect from direct sunlight.
The door stands still. E66 Motor control defective. Have the system repaired by an
expert.
Normal operation E67 Drive heavily loaded. Wait for the automatic reset
Otherwise have the system re-
paired by an expert.
Door remains open or
normal operation.
E72 Battery charge < 15 % Wait until battery is sufficiently
charged
Door remains open or
normal operation.
E73 Battery unit defective Have the system repaired by an
expert.
The door stands still. E8 ... Control system shut down for
safety reasons.
Perform a software-reset.
Have the system repaired by an
expert.
The door collides with
people.
– Safety device or setting inadequate. Shut down the system.
(see chapter 2.7).
