Instructions for use T-1321 e 3
1 General Information
1.1 Target Groups
Operator of the automatic door. The operator is the person responsible for the operation and main-
tenance of the system.
Persons instructed by the operator to carry out certain duties, for example the servicing and main-
tenance of the automatic sliding door.
1.2 Storage and Forwarding of the Manual
Store the instructions for use in the vicinity of the automatic door system.
If the manual has become illegible due to constant usage, reorder the instructions or download from:
www.tormax.com
When the door system is transferred or resaled to a third party, pass the following documents to the
new owner:
This instructions for use
Documentation concerning modification and repair work
Proof of the regular examinations System test book T-879
1.3 Area of Application
Product name, door system: Automatic sliding door
Product name, door drive: TORMAX iMotion
®
2202 Sliding Door Drive *
TORMAX iMotion
®
2202.A Sliding Door Drive
TORMAX iMotion
®
2202.A-IP68 Sliding Door Drive
TORMAX iMotion
®
2202.RETRO-TSP / TFP Sliding Door Drive *
TORMAX iMotion
®
2202.A-RETRO-TSP Sliding Door Drive
TORMAX iMotion
®
2301 / 2301.IP68 Sliding Door Drive
TORMAX iMotion
®
2302 Sliding Door Drive
TORMAX iMotion
®
2401 / 2401.IP68 Sliding Door Drive
* discontinued
The drive name is indicated in an abbreviated form in the Instructions.
The door drives are defined in more detail by a 4-figure number:
Identification plate with the serial number:
located on the drive.
Door system identification plate (example):
located on the side panel of the drive.
Contact
Manufactured
Initial
Commissioning
System No.
Sliding Door
System
TORMAX …………… .HERM
WT-299 e 3.18
DIN 18650-1:2010
N
e
x
t
S
e
r
v
i
c
e
2019
000/000/00
MM.YYYY
DD.MM.YYYY
Max Muster AG
Hauptstrasse 43 – 8049 Zürich
SERVICE: 043 827 33 55
Continuous numbering
2 = Drive for sliding door
2 – 4 = Increaing power
2 3 0 2Example
.A = New drive generation
.A-RETRO-TSP = Adapter for conversion of type TSP to iMotion 2202.A
.RETRO-TSP/TPF = Adapter for conversion of type TSP or TFP to iMotion 2202
.IP68 = Protective class of drive
