4 Instructions for use T-1321 e
1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
• Measures for averting danger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these chapters can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be reprogrammed
by a specialist.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type Electro-mechanical sliding door drive with an AC permanent magnet
synchronous motor
Control system Control unit MCU32
Mains connection 1 × 230 VAC, 50 – 60 Hz, 10 – 16 A
1 × 115 VAC, 50 – 60 Hz, 15 – 20 A
Power consumption iMotion 2202, 2202.A, 2202.A-IP68: max. 190 W
iMotion 2301, 2302: max. 190 W
iMotion 2301.IP68: max. 240 W
iMotion 2401: max. 310 W
iMotion 2401.IP68: max. 350 W
Sensor supply iMotion 2202, 2202.A, 2301, 2302: 24 V DC (+0,5 –1,5 V) 0,75 A
in battery operation min. 16,5 V
iMotion 2401: 24 V DC (+0,5 –1,5 V) 1,5 A
in battery operation min. 16,5 V
iMotion 2301.IP68: 0,75 A
iMotion 2401.IP68: 1,5 A to +30 °C, 1,0 A to +50 °C
Protective class, drive IP20: iMotion 2202, 2202.A, 2301, 2302, 2401
IP65 / IP68: iMotion 2202.A-IP68, iMotion 2301.IP68, 2401.IP68
Fuse 5 AT
Ambient temperature –20 °C bis +50 °C
Emission sound pressure
level
Typically 55 dB (A) at 50 cm/s, depending on door and substructure
Electromagnetic
compatibility (EMV)
IEC 61000-6-2, IEC 61000-6-3
Service life Tested to 1,000,000 cycles
