4
GROUNDING INSTRUCTIONS
GROUNDING
PIN
GROUNDING
OUTLET
GROUNDED
The charger must be grounded. If it should malfunction or breakdown, grounding
provides a path of least resistance for electric current to reduce the risk electric
shock. This charger is equipped with a cord having an equipment -grounding
conductor and grounding plug. The plug must be inserted into an appropriate
outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
WARNING: Improper connection of the charger -grounding conductor
can result in a risk of electric shock. Check with a qualified electrician
or service person if you are in doubt as to whether the outlet is properly
grounded. Do not modify the plug provided with the charger - if it will
not fit the outlet, have a proper outlet installed by a qualified electrician.
The charger is for use on a nominal 115-volt circuit, and has a grounding plug that
looks like the plug illustrated in sketch A.
A
