8
TECHNICAL SPECIFICATIONS
• Above values are approximate. Since the company’s policy is to continuously
improve the product, there could be changes without prior notice.
OPERATOR GUIDELINES
Let the machine do the work. Grip the handle as lightly as possible.
• Wear suitable footwear to avoid slipping.
• Do not smoke when using the machine.
Model TS040-W17-U
Voltage 25.6VDC
Vacuum motor rating 120W / 4.8 A
Brush motor rating 2 x 60W (120W)/2 x 2.34A (4.7A)
Brush speed 300 rpm
Solution tank capacity 1.3 Gallons
Recovery tank capacity 1.7 Gallons
Coverage Up to 16,685 sq.ft./hr
Cleaning width 16.92”
Squeegee width 17.72”
Weight 40.8 lbs.
Charge time 180 min.
Run time 60-75 min.
Machine dimensions 17.91 x 13.98 x 46.85
UL Listed Yes
The manufacturer cannot accept responsibility for damage
caused when the appliance is not used in accordance with the
instructions provided or for uses other than those for which it
was intended.
