15
ASSEMBLY AND OPERATION
TRANSPORT AND STORAGE
9. If the recovery tank reaches the MAX scale, it must be drained as soon as
possible (Picture 8).
Remove the latch for the recovery tank (Picture 9), lift the recovery tank to
drain the dirty water (Picture 10), and clean the recovery tank with clean water.
Put the recovery tank back on the machine and turn the latch back to the
horizontal position.
NOTE: After daily use, the recovery tank should be cleaned. If the recovery tank is
not cleaned regularly, the hose may become blocked by mud.
Picture 8
Picture 11
Picture 9
Recovery tank latchMAX fill Recovery tank handle
Picture 10
When the floor scrubber is not in use, place it vertically in a dry, flat, indoor space.
When moving the floor scrubber indoors, the wheels on the machine body can be
used to move the unit, saving time and effort. (Picture 11).
Wheel
