13
ASSEMBLY AND OPERATION
1. Remove the machine and all accessories from the packing box.
2. Place the whole machine vertically.
3. Unscrew the two screws of the battery cover and open the battery cover.
Connect the battery connection cable and screw the cover plate back on
(picture 3).
4. Brush installation (Picture 4).
The brush is a magnetic brush, which can be automatically attached when
aligned with the brush disc connector.
5. Squeegee installation (Picture 5).
First connect the suction hose with the squeegee mouth. Align and push the
hole of the squeegee onto the squeegee mouth.
Brush disc with magnet
1. Install the suction hose
2. Install the squeegee
Picture 3
Picture 4
Picture 5
