UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthe
menuaccessbuttonwhileatthemainscreen.This
willbringyoutothemainmenu.Refertothefollowing
tablesforasynopsisoftheoptionsavailablefrom
themenus:
MainMenu
MenuItemDescription
Faults
Containsalistoftherecent
machinefaults.Referto
theServiceManualoryour
AuthorizedToroDistributorfor
moreinformationontheFaults
menuandtheinformation
containedthere.
ServiceContainsinformationonthe
machinesuchashoursof
usecountersandothersimilar
numbers.
Diagnostics
Displaysthestateofeach
machineswitch,sensorand
controloutput.Youcanuse
thistotroubleshootcertain
issuesasitwillquicklytellyou
whichmachinecontrolsareon
andwhichareoff.
Settings
Allowsyoutocustomizeand
modifycongurationvariables
ontheInfoCenterdisplay.
AboutListsthemodelnumber,serial
number,andsoftwareversion
ofyourmachine.
Service
MenuItemDescription
Hours
Liststhetotalnumberofhours
thatthemachine,engineand
PTOhavebeenon,aswell
asthenumberofhoursthe
machinehasbeentransported
andservicedue.
Counts
Listsnumerouscountsthe
machinehasexperienced.
Diagnostics
MenuItemDescription
CuttingUnitsIndicatestheinputs,qualiers
andoutputsforraisingand
loweringthecuttingunits.
Hi/LowRangeIndicatestheinputs,qualiers
andoutputsfordrivingin
transportmode.
PTOIndicatestheinputs,qualiers
andoutputsforenablingthe
PTOcircuit.
EngineRun
Indicatestheinputs,qualiers
andoutputsforstartingthe
engine.
Backlap
Indicatestheinputs,qualiers
andoutputsforoperatingthe
backlapfunction.
Settings
MenuItemDescription
Units
Controlstheunitsusedonthe
InfoCenter.Themenuchoices
areEnglishorMetric
Language
Controlsthelanguageused
ontheInfoCenter*.
LCDBacklightControlsthebrightnessofthe
LCDdisplay.
LCDContrastControlsthecontrastofthe
LCDdisplay.
FrontBacklapReelSpeedControlsthespeedofthefront
reelsinbacklapmode.
RearBacklapReelSpeedControlsthespeedoftherear
reelsinbacklapmode.
ProtectedMenusAllowsapersonauthorized
byyourcompanywiththe
PINcodetoaccessprotected
menus.
AutoIdle
Controlstheamountoftime
allowedbeforereturningthe
enginetolowidlewhenthe
machineisstationary.
BladeCountControlsthenumberofblades
onthereelforreelspeed.
MowSpeedControlsthegroundspeedfor
determiningthereelspeed.
Heightofcut(HOC)Controlstheheightofcut
(HOC)fordeterminingthereel
speed.
FReelRPMDisplaysthecalculatedreel
speedpositionforthefront
reels.Thereelscanalsobe
manuallyadjusted.
RReelRPMDisplaysthecalculatedreel
speedpositionfortherear
reels.Thereelscanalsobe
manuallyadjusted.
*Only"operator-faced"textistranslated.Faults,
Service,andDiagnosticsscreensare"service-faced."
Titlesappearintheselectedlanguage,butmenu
itemsareinEnglish.
About
MenuItemDescription
Model
Liststhemodelnumberofthe
machine.
SNListstheserialnumberofthe
machine.
23
