Reelmaster 7000−D
Page 2 − 4
Product Records and Maintenance
Standard Torque for Dry, Zinc Plated and Steel Fasteners (Inch Series)
Thread Size
Grade 1, 5 &
8 with Thin
Height Nuts
SAE Grade 1 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 2 or Stronger Nuts)
SAE Grade 5 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 2 or Stronger Nuts)
SAE Grade 8 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 5 or Stronger Nuts)
in−lb in−lb N−cm in−lb N−cm in−lb N−cm
# 6 − 32 UNC
10 + 2 13 + 2 147 + 23
15 + 2 169 + 23 23 + 3 262 + 34
# 6 − 40 UNF 17 + 2 192 + 23 25 + 3 282 + 34
# 8 − 32 UNC
13 + 2 25 + 5 282 + 30
29 + 3 328 + 34 41 + 5 463 + 56
# 8 − 36 UNF 31 + 4 350 + 45 43 + 5 486 + 56
# 10 − 24 UNC
18 + 2 30 + 5 339 + 56
42 + 5 475 + 56 60 + 6 678 + 68
# 10 − 32 UNF 48 + 5 542 + 56 68 + 7 768 + 79
1/4 − 20 UNC 48 + 7 53 + 7 599 + 79 100 + 10 1130 + 113 140 + 15 1582 + 169
1/4 − 28 UNF 53 + 7 65 + 10 734 + 113 115 + 12 1299 + 136 160 + 17 1808 + 192
5/16 − 18 UNC 115 + 15 105 + 15 1186 + 169 200 + 25 2260 + 282 300 + 30 3390 + 339
5/16 − 24 UNF 138 + 17 128 + 17 1446 + 192 225 + 25 2542 + 282 325 + 33 3672 + 373
ft−lb ft−lb N−m ft−lb N−m ft−lb N−m
3/8 − 16 UNC 16 + 2 16 + 2 22 + 3 30 + 3 41 + 4 43 + 5 58 + 7
3/8 − 24 UNF 17 + 2 18 + 2 24 + 3 35 + 4 47 + 5 50 + 6 68 + 8
7/16 − 14 UNC 27 + 3 27 + 3 37 + 4 50 + 5 68 + 7 70 + 7 95 + 9
7/16 − 20 UNF 29 + 3 29 + 3 39 + 4 55 + 6 75 + 8 77 + 8 104 + 11
1/2 − 13 UNC 30 + 3 48 + 7 65 + 9 75 + 8 102 + 11 105 + 11 142 + 15
1/2 − 20 UNF 32 + 4 53 + 7 72 + 9 85 + 9 115 + 12 120 + 12 163 + 16
5/8 − 11 UNC 65 + 10 88 + 12 119 + 16 150 + 15 203 + 20 210 + 21 285 + 28
5/8 − 18 UNF 75 + 10 95 + 15 129 + 20 170 + 18 230 + 24 240 + 24 325 + 33
3/4 − 10 UNC 93 + 12 140 + 20 190 + 27 265 + 27 359 + 37 375 + 38 508 + 52
3/4 − 16 UNF 115 + 15 165 + 25 224 + 34 300 + 30 407 + 41 420 + 43 569 + 58
7/8 − 9 UNC 140 + 20 225 + 25 305 + 34 430 + 45 583 + 61 600 + 60 813 + 81
7/8 − 14 UNF 155 + 25 260 + 30 353 + 41 475 + 48 644 + 65 667 + 66 904 + 89
Reduce torque values listed in the table above by 25%
for lubricated fasteners. Lubricated fasteners are de-
fined as threads coated with a lubricant such as engine
oil or thread sealant such as Loctite.
Torque values may have to be reduced when installing
fasteners into threaded aluminum or brass. The specific
torque value should be determined based on the fasten-
er size, the aluminum or base material strength, length
of thread engagement, etc.
The nominal torque values listed above for Grade 5 and
8 fasteners are based on 75% of the minimum proof load
specified in SAE J429. The tolerance is approximately
+
10% of the nominal torque value. Thin height nuts in-
clude jam nuts.
