Reelmaster 7000−DPage 7 − 2Axles, Planetaries and Brakes
Specifications
Item Specification
Wheel lug nut torque (front and rear) 85 to 100 ft−lb (116 to 135 N−m)
Steering cylinder bolt torque 100 to 125 ft−lb (136 to 169 N−m)
Planetary, Brake Assembly and Wheel Motor
Mounting Screw Torque
OPH−2 series planetary 60 ft−lb (81 N−m)
VA02 series planetary 75 to 85 ft−lb (101 to 115 N−m)
Planetary wheel drive mounting screw torque 75 to 85 ft−lb (102 to 116 N−m)
Rear wheel toe−in 0.125 in (3 mm)
Tire pressure (front and rear) 12 to 15 psi (83 to 103 kPa)
Planetary Drive Lubricant SAE 85W−140 wt. Gear Lube
Capacity (each wheel) 16 to 20 fl oz (0.47 to 0.59 L)
Rear axle lubricant SAE 85W−140 wt. gear lube
Rear axle gear lube capacity 128 fl oz (3.31 L) total
Center Housing = 80 fl oz (2.37 L)
Outer Housings (ea.) = 16 fl oz (0.47 L)
Gearbox = 16 fl oz (0.47 L)
