E The Toro Company -- 2015, 2018, 2019, 2020
Part No. 15214SL Rev. D
Service Manual
(Models 03780/A and 03781)
Reelmaster
R
7000--D
Preface
The purpose of this publication is to provide the service
technician with information for troubleshooting, testing
and repair of major systems and components on the
Reelmaster 7000--D.
REFER TO THE TRACTION UNIT AND CUTTING
UNIT OPERATOR’S MANUALS FOR OPERATING,
MAINTENANCE AND ADJUSTMENT INSTRUC-
TIONS. For reference, insert a copy of the Operator’s
Manuals and Parts Catalog for your machine into Chap-
ter 2 of this service manual. Additional copies of the Op-
erator’s Manuals and Parts Catalog are available on the
internet at www.Toro.com.
The Toro Company reserves the right to change product
specifications or this publication without notice.
This safety symbol means DANGER, WARNING
or CAUTION, PERSONAL SAFETY INSTRUC-
TION. When you see this symbol, carefully read
the instructions that follow. Failure to obey the
instructions may result in personal injury.
NOTE: A NOTE will give general information about the
correct operation, maintenance, service, testing or re-
pair of the machine.
IMPORTANT: The IMPORTANT notice will give im-
portant instructions which must be followed to pre-
vent damage to systems or components on the
machine.
