Reelmaster 7000−D Page 4 − 7 Kubota Diesel Engine
Removal (Fig. 4)
CAUTION
The muffler and exhaust pipe may be hot. T o
avoid possible burns, allow the engine and ex-
haust system to cool before working on the muf-
fler.
1. Park machine on a level surface, lower cutting units,
stop engine, engage parking brake and remove key
from the ignition switch.
2. Raise and support hood.
3. Remove muffler and/or muffler bracket from the en-
gine as necessary.
Installation (Fig. 4)
IMPORTANT: If exhaust studs were removed from
engine cylinder head, thoroughly clean threads in
head and apply Loctite #277 (or equivalent) to stud
threads before installing studs into head.
NOTE: Make sure muffler flange and exhaust manifold
sealing surfaces are free of debris or damage that may
prevent a tight seal.
1. Install new exhaust gasket if original gasket is dam-
aged or torn.
IMPORTANT: Failure to follow the suggested ex-
haust system fastener sequence may result in pre-
mature muffler failure.
2. Install exhaust system components to the engine.
Hand tighten all exhaust system fasteners before fully
tightening any fastener.
3. Tailpipe should have equal clearance between frame
and engine after installation.
4. Lower and secure hood after exhaust system instal-
lation is complete.
Kubota
Engine
