ServicingtheCuttingBlades
ServiceInterval:Yearly
Important: Y ou will need a torque wr ench to install the
blades pr oper l y . Ifyoudonothaveatorquewrenchor
areuncomfortableperformingthisprocedure,contact
anAuthorizedServiceDealer.
Examinethebladesforsharpnessandanywearordamage
wheneveryourunoutofgasoline.Ifthebladeedgesare
dullornicked,havethemsharpenedorreplacetheblades.
Ifabladeisworn,bent,damagedorcracked,replaceit
immediatelywithagenuineTororeplacementblade.
DANGER
Awornordamagedbladecanbreak,andapiece
ofthebladecouldbethrowntowardtheoperator
orabystander,resultinginseriouspersonalinjury
ordeath.
•Inspectthebladesperiodicallyforwearor
damage.
•Replaceawornordamagedblade.
Note:Maintainsharpbladesthroughoutthecuttingseason,
becausesharpbladescutcleanlywithouttearingorshredding
thegrassblades.
PreparingtoServicetheCuttingBlades
1.Lockthehandleintheverticalposition(Figure40);
refertoAdjustingtheHandleHeight(page10).
1
G025927
Figure40
1.Handlelockedintheverticalposition
2.Tipthemachineontoitsside,withthedipstickdown,
untiltheupperhandlerestsontheground.
WARNING
Thebladesaresharp;contactingabladecould
resultinseriouspersonalinjury.
•Disconnectthewirefromthesparkplug.
•Weargloveswhenservicingtheblade.
InspectingtheBlades
ServiceInterval:Beforeeachuseordaily
1.Inspectthecuttingedges(Figure41).Iftheedgesare
notsharporhavenicks,removethebladesandhave
themsharpenedorreplacethem.
g017223
Figure41
1.Cuttingedge3.Wear/slotforming
2.Curvedarea4.Crack
2.Inspectthebladesthemselves,especiallythecurved
area(Figure41).Ifyounoticeanydamage,wear,ora
slotforminginthisarea,immediatelyreplaceitwith
anewblade.
DANGER
Ifyouallowabladetowear,aslotwillform
betweenthesailandatpartoftheblade.
Eventuallyapieceoftheblademaybreak
offandbethrownfromunderthehousing,
possiblyresultinginseriousinjurytoyouor
bystanders.
•Inspectthebladeperiodicallyforwearor
damage.
•Nevertrytostraightenabladethatisbent
orweldabrokenorcrackedblade.
•Replaceawornordamagedblade.
3.Checkforbentblades;refertoCheckingforBent
Blades(page21).
