AWDFrontTransmissionInstallation(continued)
g359933
Figure152
1.CableReturnSpring2.FrontTractionCableAnchor
7.Installthetransmissionreturnspringontotheshoulderboltandtransmission
bracket.
g360054
Figure153
8.Installtheupperintaketothedeck.UpperIntakeInstallation(page6–19)
9.InstalltheAWDfrontwheels.AWDFrontWheelInstallation(page7–8)
10.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
11.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
