Toro 21464 - Brake Cable Replacement

BrakeCableReplacement
BrakeCableRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.Removethebrakecablefromthecableanchor.
g352637
Figure12
6.Ata90ºangle,removethebrakecablefromthePERSONALPACE®handle.
g352638
Figure13
7.Removethezbendofthebrakecablefromthebail.
