RWDFrontHeight-of-CutRemoval(continued)
g352366
Figure97
1.Height-of-CutLever
3.MountBushing
2.FrontPivotArm
9.Removethe2(5/16–18inch)screwsand2nutssecuringtheheight-of-cut
platetotheLHdeck.Removetheheight-of-cutplatefromtheLHdeck.
RepeatontheRHsideoftheunit.
g352391
Figure98
RWDFrontHeight-of-CutInstallation
1.Installthefrontheight-of-cutplatetotheLHdeckandsecurewith2(5/16–18
inch)screwsand2nuts.T orquethenutsto19.2±3.39N•m(170±30
in-lb).RepeatontheRHsideoftheunit.
