Toro 22327 - Accessing Internal Components

RemovingandStoringthe
CylinderLocks
Important:Removethecylinderlocksfromthe
rodsandfullysecuretheminthestorageposition
beforeoperatingthemachine.
1.Starttheengine.
2.Raisetheloaderarmstothefullyraisedposition.
3.Shutofftheengineandremovethekey.
4.Removethepinssecuringthecylinderlocks.
5.Placethecylinderlocksonthepostsonthe
sidesofthemachineandsecurewiththepins.
6.Lowertheloaderarms.
AccessingInternal
Components
WARNING
Openingorremovingcovers,hoods,and
screenswhiletheengineisrunningcould
allowyoutocontactmovingparts,seriously
injuringyou.
Beforeopeninganyofthecovers,hoods,and
screens,shutofftheengine,removethekey
fromthekeyswitch,andallowtheengineto
cool.
OpeningtheHood
1.Loosenthehood-lockingscrew(Figure32)
g031215
Figure32
1.Hood-lockingscrew3.Hood
2.Hood-latchlever
2.Turnthehoodlatchclockwise(Figure32).
3.Liftuponthehandlesandswingthehoodup
(Figure32).
4.Securetheproprod.
ClosingtheHood
1.Liftuponthetabsecuringtheproprod(Figure
33)
g031216
Figure33
1.Prop-rodtab
2.Lowerthehoodandsecureitbypushingdown
onthefrontofthehooduntilitlocksinplace.
3.Tightenthehood-lockingscrewtosecurethe
latch(Figure32).
OpeningtheRear-AccessCover
1.Removethefastener(Figure34).
g031217
Figure34
1.Fastener
2.Lifttherear-accesscoveruptoaccessthe
internalcomponents(Figure34).
3.Lowertherear-accesscoverandinstallthe
fastenertoclosethecover.
27
