Toro 22327 - Electrical System Maintenance; Electrical System Safety; Servicing the Battery

ElectricalSystem
Maintenance
ElectricalSystemSafety
•Disconnectthebatterybeforemakinganyrepairs;
refertoUsingtheBattery-DisconnectSwitch(page
35).
•Chargethebatteryinanopen,well-ventilated
area,awayfromsparksandames.Unplugthe
chargerbeforeconnectingordisconnectingthe
battery.Wearprotectiveclothinganduseinsulated
tools.
•Batteryacidispoisonousandcancauseburns.
Avoidcontactwithskin,eyes,andclothing.Protect
yourface,eyes,andclothingwhenworkingwitha
battery.
•Batterygasescanexplode.Keepcigarettes,
sparks,andamesawayfromthebattery.
ServicingtheBattery
ServiceInterval:Every50hours
UsingtheBattery-Disconnect
Switch
WARNING
Contactwithhotsurfacesmaycausepersonal
injury.
Keepyourhands,feet,face,clothingand
otherbodypartsawaythemuferandother
hotsurfaces.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Openthehood,securetheproprod,andremove
theleftsidescreen.
4.Turnthebattery-disconnectswitchtotheONor
OFFpositiontoperformthefollowing:
•Toenergizethemachineelectrically,rotate
thebattery-disconnectswitchclockwiseto
theONposition(Figure48).
•Tode-energizethemachineelectrically,
rotatethebattery-disconnectswitch
counterclockwisetotheOFFposition(Figure
48).
g033901
Figure48
1.Battery-disconnect
switch—OFFposition
3.Jumppost
2.Battery-disconnect
switch—ONposition
35
