Toro 22327 - Checking the Hydraulic-Fluid Level; Replacing the Hydraulic Filter

Checkingthe
Hydraulic-FluidLevel
ServiceInterval:Every25hours
Important:Alwaysusethecorrecthydraulic
uid.Unspecieduidswilldamagethehydraulic
system.RefertoHydraulicFluidSpecications
(page47).
1.Removeanyattachments.
2.Parkthemachineonalevelsurface.
3.Raisetheloaderarmsandinstallthecylinder
locks.
4.Shutofftheengineandremovethekey.
5.Openthehoodandsecuretheproprod.
6.Removetherightsidescreen.
7.Cleantheareaaroundthellerneckofthe
hydraulictank(Figure70).
g029748
Figure70
1.Filler-neckcap
8.Removetheller-neckcapandchecktheuid
levelonthedipstick(Figure71).
Note:Theuidlevelshouldbebetweenthe
2notchesofthedipstickwhilethearmsare
loweredoratthelowernotchwhilethearms
areraised.
g029729
Figure71
1.Fillerneck2.Dipstick
9.Ifthelevelislow,addenoughuidtoraiseitto
theproperlevel.
10.Installtheller-neckcap.
11.Installthesidescreen.
12.Closethehood.
13.Removeandstorethecylinderlocksandlower
theloaderarms.
ReplacingtheHydraulic
Filter
ServiceInterval:Aftertherst8hours
Every200hours
Important:Donotsubstituteanautomotiveoil
lter;otherwise,severehydraulicsystemdamage
mayresult.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Openthehoodandsecuretheproprod.
4.Placeadrainpanunderthelterandreplace
thelter(Figure72).
