1.Lowerthecuttingunittotheshopoor.Remove
thebeltcoversfromthetopofthecuttingunitand
setthecoversaside.
2.Usingatorquewrenchorsimilartool,movetheidler
pulley(
Figure30)awayfromthedrivebelttorelease
thebelttensionandallowthebelttobeslippedoff
thegearboxpulley(Figure31).
Figure30
1.Idlerpulley
Figure31
1.Gearbox
3.Removetheoldbeltfromaroundthespindlepulleys
andidlerpulley.
4.Routethenewbeltaroundthespindlepulleysand
idlerpulleyassemblyasshownin
Figure32.
Figure32
1.Beltrouting
5.Installthebeltcovers.
