8
SPECIFICATIONS
TRACTION UNIT
Engine: Peugeot, four-cycle, four cylinder, 1.9 liter
(1900 cc) displacement, liquid cooled diesel engine.
23.5:1 compression ratio. Low idle - 1600 rpm, high
idle - 2800 ± 30 rpm. Oil capacity is 5.3 qts. with filter.
Cooling System: Capacity is 3.5 gal. of 50/50 mixture
of Peugeot recommended anti-freeze.
Fuel System: Capacity is 12 gal. of #1 or #2 diesel fuel.
Hydraulic System: Reservoir capacity is 6.5 gal.
Replaceable spin-on filter element.
Traction System: Ground speed: Low Range; 0 6.5
m.p.h (0 - 5.5 m.p.h. with mechanical speed limiter
interlock) forward and 0 3 reverse. High Range; 015
mph (0 - 12.4 m.p.h. with mechanical speed limiter
interlock) forward and 05 mph reverse.
Front Axle: Two speed axle is designed to withstand
heavy duty slope operation and side loading. Separate
mowing and transport selections for faster and more
efficient machine operation. Neutral position allows
easy towing.
Rear Axles: Two Wheel Drive - The large diameter
wheel spindles are designed for durability and long
wear, yet provide superior stability and maneuverability.
Four Wheel Drive Heavy duty, agricultural type.
Hydraulic drive with on demand" bidirectional clutch
and balanced weight distribution provides superior
traction on hillsides.
Tires/Wheels: High flotation turf tread tires on
de-mountable rims. Front tires: (2) 26 x 12.0-12, 8 ply.
Rear tires: (2) 20 x 10.0-10, 6 ply. Tire pressure 20 psi.
Seat: Adjustable fore and aft travel and weight.
Diagnostic System: Test ports for: Forward and
reverse traction (2 wheel drive), front and rear axle
motors (4 wheel drive), lift and counterbalance circuit,
steering circuit and charge circuit.
Steering System: Automotive type, full power.
Brakes: Totally enclosed, non asbestos, dry multidisc
55/8" individual wheel and parking brakes on front
traction wheels. Brakes controlled by individual pedals
operated by the left foot. Dynamic braking through
closedloop hydrostatic drive.
Electrical System: 12 volt battery with 650 cold
cranking Amps @ 0 F. 55 amp amp alternator,
ammeter, starter, key switch and automatic temperature
controlled glow plug controller. Separately fused, run,
deck and instrument/accessory circuits.
Interlock System: Designed to stop engine if operator
gets off seat while cutting deck drive switch is engaged
or traction pedal is forward or reverse. Prevents engine
from starting unless traction pedal is in neutral and
cutting deck is disengaged. Prevents cutting deck from
operating unless axle shift is in LO range. Engine will
stop if machine comes out of neutral with parking brake
set.
Warning Lights:
Glow plug indicator
Engine oil pressure warning
Engine coolant temperature warning
Charge indicator
Water in fuel
Low water indicator
Indicators:
Engine coolant temperature gauge
Fuel gauge
Hour meter
GENERAL SPECIFICATIONS (approx.):
Overall Length:
With deck installed 134 in.
Overall Width:
Transport 75 in.
Mowing 127 in.
Height: 58 in.
With ROPS installed 82in.
Wheel Tread:
(Front) 51 in.
(Rear) 41 in.
Wheel Base: 52 in.
Dry Weight:
2 Wheel Drive 3,800 lbs.
4 Wheel Drive 3,900 lbs.
OPTIONAL EQUIPMENT
Broom Kit Contact Your Local Toro Distributor
Snowthrower Contact Your Local Toro Distributor
Roll Over Protection Kit Contact Your Local Toro
Distributor (Standard on Model 30455)
4 Post Canopy Kit Contact Your Local Toro Distributor
Spark Arrestor Muffler Part No. 94-5637
Segmented Wheel Kit Part No. 76-1880
Brake Light Kit Part No. 92-7763
Windshield Kit Contact Your Local Toro Distributor
Cruise Control Kit Model No. 30485
Road Light Kit Model No. 30471
Cab Contact Your Local Toro Distributor
Additional Weights Contact Your Local Toro Distributor
Low Seat Option Contact Your Local Toro Distributor
Specifications and design subject to change without
notice.
