108-4044
1.Lowerthecuttingunit(s).
6.Fast
11.PowerTake-off(PTO)
2.Raisethecuttingunit(s).7.Continuousvariablesetting
12.High
3.Rightcuttingunit(GM4700-Donly)8.Slow
13.Low
4.Centercuttingunits
9.Engage14.Transmission
5.Leftcuttingunit(GM4700-Donly)
10.Disengage
106–9290
1.Input5.Inseat
9.Output13.Start
2.Backlap
6.PTOswitch10.PTO
14.Power
3.Hightempshutdown
7.Parkbrakeoff11.Start
4.Hightempwarning(not
used)
8.Neutral12.ETR
