Toro 30856 - Premaintenance Procedures; Removing the Hood; Lubrication; Greasing the Bearings and Bushings

Premaintenance
Procedures
RemovingtheHood
Togainadditionalaccesstoenginecompartment,the
hoodmayberemovedfromtractionunit.
1.Releasehoodlatches(Figure22)andraisehood.
Figure22
1.Hoodlatch
2.Unhooklanyardfromhoodpin,removepinand
slidehoodtubesrearwardoffguides(Figure23).
Figure23
1.Hoodpin
Lubrication
GreasingtheBearingsand
Bushings
ServiceInterval:Every50hours
Themachinehasgreasettingsthatmustbelubricated
regularlywithNo.2GeneralPurposeLithiumBase
Grease.Ifthemachineisoperatedundernormal
conditions,lubricateallbearingsandbushingsafter
every50hoursofoperationorimmediatelyafterevery
washing.
Thegreasettinglocationsandquantitiesareasfollows:
•Brakeshaftpivotbearings(5)(Figure24)
Figure24
•Rearaxlepivotbushings(2)(Figure25)
Figure25
•Steeringcylinderballjoints(2)(Figure26)
