Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
SeatKit,Model30398(soldseparately)
1
SeatSuspensionKit,Model30312
(Mechanical)or30313(Air)(sold
separately)
1
Seatbelt
1
Capscrew,7/16-20x1inch
2
Lockwasher,7/16inch
2
ManualTube1
1
R-clamp2
Installtheseat,seatbelt,andmanual
tube.
2
WarningDecal1
Usedonlyonmachinesoutsidethe
U.S.A.
3
Nopartsrequired
–
Greasethemachine.
4
Nopartsrequired
–
Checktherearaxlelubricant,hydraulic
uid,andengineoillevels
Operator’sManual
1
EngineOperator’sManual
1
PartsCatalog
1
OperatorTrainingMaterial
1
5
Pre-deliveryInspectionSheet
1
Readthemanualsandwatchthe
trainingmaterialbeforeoperatingthe
machine.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
InstallingtheSeat,SeatBelt,
andManualTube
Partsneededforthisprocedure:
1
SeatKit,Model30398(soldseparately)
1
SeatSuspensionKit,Model30312(Mechanical)or
30313(Air)(soldseparately)
1
Seatbelt
2
Capscrew,7/16-20x1inch
2
Lockwasher,7/16inch
1ManualTube
2R-clamp
Procedure
Themachineisshippedwithouttheseatassembly.
DeluxeSeatKit,ModelNo.30398,andSeatSuspension
Kit,ModelNo.30312or30313,mustbepurchasedand
installed.
1.Mountthemanualtubetotheseatsuspensionwith
the2R-clampsincludedinlooseparts(Figure3).
2.Installtheseatbelttoeachsideoftheseatwithabolt
andlockwasher,suppliedinlooseparts(Figure3).
Theseatbeltretractoristobemountedtotheright
sideoftheseatandtheseatbeltbuckletotheleft
side.
Important:Makesurethattheseatswitchis
connectedtotheseatswitchconnectoronthe
harness.
