Operating the Speed
Selector
The speed selector has 6 forward and 2 reverse
gears. T o change speeds, release the traction lever
and shift the speed-selector lever to the desired
position ( Figure 19 ). The lever locks in a notch at
each speed selection.
g001012
Figure 19
Operating the
Auger/Impeller Drive
1. T o engage the auger/impeller drive, squeeze
the right (auger/impeller) lever to the handgrip
( Figure 20 ).
g001013
Figure 20
2. T o stop the auger and impeller , release the right
lever .
Important: When you engage both the
auger/impeller lever and the traction lever ,
the traction lever locks the auger/impeller
lever down, freeing your right hand. T o
release both levers, simply release the left
(traction) lever .
3. If the auger and impeller continue to rotate when
you release the auger/impeller lever , do not
operate the machine. Check the auger/impeller
cable; refer to Checking and Adjusting the
Auger/Impeller Cable ( page 21 ) and adjust it if
necessary . Otherwise, take the machine to an
Authorized Service Dealer for service.
W ARNING
If the auger and impeller continue
to rotate when you release the
auger/impeller lever , you could seriously
injure yourself or others.
Do not operate the machine. T ake it to an
Authorized Service Dealer for service.
Operating the Quick Stick
®
Hold the blue trigger cap down to use the Quick Stick
to move the discharge chute and the chute deector .
Release the trigger cap to lock the discharge chute
and chute deector into position ( Figure 21 ).
g001014
Figure 21
Moving the Discharge Chute
Hold the blue trigger cap down and move the Quick
Stick to the left to move the discharge chute to the
left; move the Quick Stick to the right to move the
discharge chute to the right ( Figure 22 ).
g018894
Figure 22
16
